380V Isolation Transformer Outdoor Voltage Power Transformer IP44 56 64

Name: 380V Isolation Transformer Outdoor Voltage Power Transformer IP44 56 64
Brand: SHLEIPUSI Or Support OEM/ODM Service
Price: 1 USD

Buy cheap 380V Isolation Transformer Outdoor Voltage Power Transformer IP44 56 64 product

Brand Name : SHLEIPUSI Or Support OEM/ODM Service

Model Number : SG-200KVA Or Customized

Certification : CE;ISO9001;UL

Place of Origin : Shanghai

MOQ : 1

Price : 1 pc≤Qty≤5 pcs 1950USD; 5 pcs＜Qty≤100 pcs 1850USD; 100pcs＜Qty 1880USD

Payment Terms : T/T,D/P,D/A,L/C,Western Union,Alipay,Wechat pay

Supply Ability : 1000000PCS

Delivery Time : 1 pc≤Qty≤5 pcs 1-7 working days; 5 pcs＜Qty≤100 pcs 7-14 working days; 100pcs＜Qty More than 14 working days

Packaging Details : Non-fumigation plywood case ; Reference packing size: 106X80X124CM; Reference weight: 513KG

Product name : Outdoor Use 3 Phase Isolation Transformer

Place of origin : Shanghai, PRC

Rated capacity : 200KVA Or Customized

Product model : SG-200KVA Or Customized

Rated input voltage : Three phase 400V 380V 440V or Customized

Rated output voltage : Three phase 380V 220V 200V 173V or Customized

Output precision : ±2%

Working temperature : －15℃~＋45℃

Insulation resistance : ≥5MΩ

Contact Now

Outdoor Use 3 Phase Isolation Transformer | Industrial Dry Type Isolation Transformers for Global Outdoor Applications

Contact Us

Tel: +86 15926315252 | Mobile/WeChat: +86 15926315252 | Email: daniel@shlepus.com | WhatsApp: +86 18979230829

Product Introduction

Our Outdoor Use 3 Phase Isolation Transformer (SG Series) is a rugged industrial-grade dry-type power solution, engineered with premium electrical isolation performance and all-weather outdoor protection for global industrial power systems. With a standard 200KVA rated capacity (fully customizable) and flexible voltage configurations (input 380V/400V/440V, output 380V/220V/200V/173V, customizable), this transformer delivers complete galvanic isolation to eliminate common-mode interference, protect sensitive equipment, and ensure stable full-capacity operation. It is the ideal power solution for outdoor factory power distribution, photovoltaic systems, EV charging stations, CNC machine tools, laser cutters, medical equipment, generators and precision instruments, trusted by electrical engineers and industrial operators worldwide.

Key Features & Competitive Advantages

Superior Galvanic Isolation Performance: Dual-winding isolation design eliminates electrical interference, protects personnel and sensitive equipment, with 3500V di-electrical strength withstand, ≥5MΩ insulation resistance and 4% short-circuit resistance for maximum safety.
Rugged All-Weather Outdoor Protection: Customizable IP23/IP44/IP56/IP64 enclosure delivers reliable dust, rain and corrosion resistance, adapting to -10℃~+45℃ working conditions, 30%-80% ambient humidity and altitudes below 3500m.
High-Efficiency Energy-Saving Design: New high-permeability silicon steel core enables noise-free (＜55dB) operation, ultra-low energy losses, ≥90% working efficiency and no additional waveform distortion, drastically cutting long-term operational costs.
Safe & Durable Construction: High-purity winding material delivers strong conductivity and low temperature rise (＜80K); Class F insulation, high-insulation reliable terminals, safety trip lock and premium nylon insulation frame guarantee long service life.
User-Friendly Smart Design: Digital display for real-time working status monitoring, input/output indicators, optimized heat emission holes, convenient wiring structure and brake-equipped universal wheels simplify outdoor installation and maintenance.

Why Choose Our Outdoor Use 3 Phase Isolation Transformers

Full OEM/ODM Customization: We offer end-to-end customization for power, voltage, protection level, appearance, logo branding and packaging, plus free professional product photography and video producing services.
Rigorous Full-Process Quality Control: Every unit undergoes professional inspection from raw material intake to final assembly, with strict pre-shipment testing to ensure zero-defect delivery for harsh outdoor environments.
Global Logistics & Coverage: We support all mainstream transportation modes (sea, air, land, express, railway) and international trade terms (EXW, FOB, CIF, DDP, etc.), serving markets across Central Asia, East Asia, South Asia, Africa, South America and North America.
Lifetime After-Sales Support: We provide lifetime free telephone technical guidance, remote video installation support, free component replacement for warranty-covered quality issues, and optional on-site engineer services.
Flexible Production & Low MOQ: Monthly output reaches 10,000 units for small-power models and 2,000 units for large-power transformers, with a minimum order quantity of just 1 set for samples and bulk orders.

Technical Specifications

Item	Specification
Product Name	Outdoor Use 3 Phase Isolation Transformer
Brand	SHLEIPUSI (Customizable Supported)
Place of Origin	Shanghai, PRC
Rated Capacity	200KVA (Customizable)
Product Model	SG-200KVA (Customizable)
Rated Input Voltage	Three Phase 380V, 400V, 440V (Customizable)
Rated Output Voltage	Three Phase 380V, 220V, 200V, 173V (Customizable)
Working Frequency	50/60Hz
Output Precision	±2%
Insulation Class	F
Protection Class	IP23/IP44/IP56/IP64 (Customizable)
Cooling Method	Dry Type Air Cooling
Working Efficiency	≥90%

380V Isolation Transformer Outdoor Voltage Power Transformer IP44 56 64

Frequently Asked Questions (FAQ)

How long is the lead time?

3-7 working days for standard products, 10-30 working days for custom orders based on quantity and requirements.
How do you control product quality?

We conduct professional inspection at every production stage, and only ship products meeting strict international quality standards after full pre-shipment testing.
What are your payment terms?

30% deposit for standard products, 50% advance for custom orders, with full balance paid before shipment.
Can you provide installation technical support?

Yes, our professional technical team offers full installation guidance and application support for global outdoor and indoor projects.
What is your product packaging?

Large transformers use reinforced wooden cases, small products use high-strength cartons, with custom packaging available upon request.
Can you print our logo on the product?

Yes, we provide full OEM/ODM services, including custom logo placement on products, manuals and technical documents for eligible bulk orders.
What is your main market?

Our products are sold worldwide, covering core markets including Central Asia, East Asia, South Asia, Africa, South America and North America.
What is your production capacity?

Up to 10,000 units/month for small-power products, and 2,000 units/month for large-power industrial transformers.
What is your MOQ?

Our minimum order quantity is 1 set, supporting both sample testing and bulk procurement for outdoor industrial projects.
